مولتی متر حرفه ای و صنعتی True RMS یونیتی مدل UNI-T UT171A

UNI-T UT181A

:SPECIFICATIONS
DC Voltage 60mV/600mV/6V/60V/600V/1000V ±(0.025%+5)
AC Voltage 60mV/600mV/6V/60V/600V/1000V ±(0.3%+30)
DC Current 600μA/6000μA/60mA/600mA/10A ±(0.08%+10)
AC Current 600μA/6000μA/60mA/600mA/10A ±(0.6%+20)
Resistance 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ±(0.05%+2)
Admittance 60nS ±(2%+10)
Capacitance 6nF/60nF/600nF/6μF/600μF/6mF/60mF ±(2%+5)
Frequency (Hz) 10Hz - 60MHz ±(0.01%+5)
Temperature -40°C°~1000°C * ±(1.5%+50)

:FEATURES
Display Count 60000
Auto Range
Manual Range
True RMS
Bandwidth 100kHz
AC+DC
Low Pass Filter
dBV/dBm
Continuity Buzzer
Diode
Duty Cycle
Dual Temperature Measurement
Data Hold
Peak Hold
Relative Mode
Datalogging 20000
Trend Capture
MAX/MIN/AVG
Date Time Display
Data Comparison
Display Type 3.5" 320x240 64k colour
Backlight Adjustment
Analogue Bargraf
USB Interface
Mis-Plug Alarm
Battery Indication
Auto Power Off
Re-Chargeable Battery
Input Protection
Input Impedance DCV 10MΩ+

:GENERAL CHARACTERISTICS
Power: 7.4V 2200mAh Li-ion Battery
Weight: 638.6g
Size: 103x225x59mm
LCD Size: 70x52mm
Accessory: Battery, Test Lead, Temperature Adaptor, Point Contact Temperature Probe x2, Power Adaptor, PC software CD, USB interface cable
